Submersible Cutter Pump

Flowline submersible cutter pumps are specifically designed for wastewater applications containing fibrous materials that clog conventional sewage pumps. The integrated cutting system features a hardened steel cutter plate that shreds rags, wipes, sanitary products, and organic matter into small particles before pumping.

Manufactured at our ISO 9001:2015 certified facility in Gujarat, our cutter pumps use a precision-engineered cutting mechanism with S-shaped impeller that rotates against a stationary cutting ring. This dual-action system reduces solids to a pumpable size, preventing clogging and ensuring uninterrupted operation.

Flowline cutter pumps are ideal for locations where conventional sewage pumps face frequent clogging from fibrous waste — including hotels, hospitals, shopping malls, residential townships, and municipal lift stations.

Category:

Description

Specification Details
Flow Range Up to 100 m³/hr
Head Range Up to 22 meters
Solid Handling (Pre-Cut) Fibrous materials, rags, wipes — shredded to pumpable size
Max Particle Size (Post-Cut) Up to 50mm shredded particles
Motor Power 1.5 HP to 15 HP
Power Supply 3-Phase, 415V, 50Hz
Speed 2-Pole (2900 RPM) / 4-Pole (1450 RPM)
Insulation Class Class F
Sealing Double mechanical seal (SiC / TC) + oil chamber
Cutting System S-shaped impeller + stationary cutting ring (HCR 55+)
Material Cast iron (FC 250 grade) + SS cutting components
Discharge Size 50mm to 100mm
Max Fluid Temperature 40°C (standard)
Duty Cycle Continuous (S1)
